BXF-3*10W
Sungold Integrated solar panels BXF-3*10W
BXF-3*10W is the best integrated solar panels, portable, durable, foldable and lightweight. Sungold BXF-3*10W consists of 3 10W monocrystalline solar panels. This BXF-3*10W portable solar panel can charge mobile phones and tablets, and is the best choice for outdoor and off-grid application scenarios.
You can take this 30W portable solar panel with you when you go out, hike, fish, camp or hike, so that your devices will never run out of power when the sun is full.
make the most of every sunlight
Features
Foldable and waterproof
Lightweight and portable
High conversion rate
Excellent cost performance
Foldable and waterproof
The best portable solar charger BXF-3*10W is foldable, which is easier to carry after folding. It also adopts a waterproof design with an IP68 waterproof rating on the back to prevent occasional rain and wet fog. Keep the port dry while charging.
Lightweight and portable
This Sungold BXF-3*10W all-in-one portable solar panel is made of ETFE surface material. The carefully crafted ETFE laminate is highly waterproof, flame-retardant, dust-proof and self-cleaning, making this portable solar charger virtually indestructible and extremely durable. This solar panel is suitable for a variety of outdoor environments and has a long service life.
High Conversion Rate
The portable solar panel BXF-3*10W adopts one-piece lamination technology, which improves the conversion efficiency. The BXF charging pack can provide you with more power and provide sufficient power support for your outdoor activities.
Excellent cost performance
Sungold BXF series all-in-one portable solar panels have an extremely reasonable cost price structure, which makes the product stand out from other similar products. The 3 compact solar panels fold into a tablet size of only 0.9 kg, which can be easily carried for outdoor activities.
Applications
Frequently Asked Questions
Sungold BXF-3*10W foldable solar panel weighs 0.9kg, 675*325*3mm (unfolded), 325*222*35mm (folded), easy to carry, install and transport.
Yes, our 30W solar panel supports fast charging. If the solar panel is powered, the LED light will light up red. If there is no sunlight, the red light will go out. Since the output power varies with sunlight exposure, it is normal to have flashing lights sometimes.
We recommend that you connect your USB device to this solar charger in a place with direct sunlight and no shade. It is not recommended to use portable solar panels in rainy and humid environments, because the solar panel can only quickly power your device when there is sufficient sunlight.
With 2 output ports (1*USB, 1*Type-C), it can charge 2 devices at the same time. If thick clouds pass by, it will pause charging and restart when the sun shines again.
Sungold BXF Series 30W Solar Panel is compatible with most mobile phones, power banks, tablets, Kindle, etc.
Specifications
Maximum power(Pmax)
30W
Open-circuit voltage(Voc)
12.2V
Voltage at Pmax(Vmp)
10.4V
Short-circuit current(Isc)
3.03A
Current at Pmax(Imp)
2.89A
Cells efficiency(%)
22.70%
The maximum system voltage
200V DC
Power temperature coefficient
-0.38%/℃
Voltage temperature coefficient
-0.36%/℃
Current temperature coefficient
0.05%/℃
Operating temperature
-10~60℃
Weight
0.9KG
Folding Size
325*222*35mm
Unfold Size
675*325*3mm
Warranty
1 year
Download Specs
