Sungold Integrated solar panels BXF-4*30W
Foldable and waterproof
Lightweight and portable
The portable solar panel BXF-4*30W adopts one-piece lamination technology, which improves the conversion efficiency. The BXF charging pack can provide you with more power and provide sufficient power support for your outdoor activities.
Sungold BXF-4*30W foldable solar panel weighs 3.41kg, 1665*470*3mm (unfolded), 470*413*37mm (folded), easy to carry, install and transport.
Yes, our 120W solar panel supports fast charging. If the solar panel is powered, the LED light will light up red. If there is no sunlight, the red light will go out. Since the output power varies with sunlight exposure, it is normal to have flashing lights sometimes.
We recommend that you connect your USB device to this solar charger in a place with direct sunlight and no shade. It is not recommended to use the portable solar panel in rainy and humid environments, because the solar panel can only quickly power your device in full sunlight.
With 3 output ports (1*USB, 1*Type-C, 1*DC). If thick clouds pass by, it will pause charging and restart when the sun shines again.
Sungold BXF Series 120W Solar Panel is compatible with most mobile phones, power banks, tablets, Kindle, etc. You can charge up to 3 devices at the same time.
Maximum power(Pmax)
120W
Open-circuit voltage(Voc)
24.4V
Voltage at Pmax(Vmp)
20.9V
Short-circuit current(Isc)
6.03A
Current at Pmax(Imp)
5.75A
Cells efficiency(%)
22.70%
The maximum system voltage
200V DC
Power temperature coefficient
-0.38%/℃
Voltage temperature coefficient
-0.36%/℃
Current temperature coefficient
0.05%/℃
Operating temperature
-10~60℃
Weight
3.41KG
Folding Size
470*413*37mm
Unfold Size
1665*470*3mm
Warranty
1 year
