What affects the service life of solar modules? -10 influencing factors

SunGold
Sungold

Solar panels have a long lifespan, but there are still many factors that affect the lifespan of solar panels. Understanding the following 10 points will help you to use solar panels better.

1. Degradation and failure modes

Because it has no moving parts (a major source of reliability problems in other types of power generation systems), the operational life of a PV module may be determined by the stability and corrosion resistance of the materials used in the solar panel. Manufacturers’ warranties of up to 40 or 50 years for solar charging panels are indicative of the quality of bulk silicon PV modules being produced today. However, there are several failure modes and degradation mechanisms that may reduce power output or cause solar panels to fail. Almost all of these mechanisms are related to water ingress or temperature stress.

2. Reversible reduction in power output

A solar panel may reduce output for reversible reasons. It may be affected by shadows, for example, a tree growing in front of it. The surface of the solar panel may have been soiled (solar panels typically have up to a 10% loss of output due to a soiled surface). A solar PV panel may have failed, or the interconnection between solar power panels may have changed where the array is operating. However, these reductions in power are reversible, as long as the original cause is corrected

3. Degradation and failure of PV modules

Degradation mechanisms may involve a gradual reduction in the output power of the PV module over time or an overall reduction in power due to the failure of a single solar cell in the solar panel.

4. The degradation of solar cells

The gradual decline in the performance of the module may be caused by the following reasons
A. Rs increase due to the decrease in adhesion or corrosion of the contact points (usually caused by water vapor).
B. Decrease in Rush due to migration of metal through p-n junction, or deterioration of anti-reflection coating.

5.Short circuit of the cell

Short circuits may occur at the interconnection of cells, which is also a common failure mode of thin film cells. Because the top and rear contact points are closer together, it is more likely to be shortened by pinholes or areas where the cell material is corroded or damaged.

6.Solar panel short circuit

Although each solar panel is tested before it is sold, solar panel shorts are often the result of manufacturing defects. They occur when the insulation layer degrades with weathering, leading to delamination, cracking, or galvanic corrosion.

7.Solar photovoltaic panels’ glass breakage

Shattering of the top glass surface may occur due to vandalism, thermal stress, handling, wind, or hail.

8.Solar panel delamination

In the early modules, module delamination was a common failure mode and is no longer a problem. It is usually caused by a reduction in bond strength either from environmentally induced moisture or photothermal aging, and stress caused by varying thermal and humidity expansion.

9.Hot spot failure

Mismatched, cracked, or shadowed cells can cause hot spot failures.

10.Bypass diode failure

The bypass diode itself, used to overcome cell mismatch problems, can also fail, usually due to overheating, usually due to under sizing. If the junction temperature is kept below 128°C, this problem will be minimized.

There are many factors that can affect solar panels. What else do you know? Want to know more about solar panels welcome to Sungold Solar.
